Technical Specifications
Detailed technical information for this product.
OS
Embedded ViewBoard OS
GPU
ARM Mali450 MP4
CPU
ARM Cortex A53 Quad Core Processor 1.5GHz
Memory
2GB
Storage
16GB
Built-in Software
myViewBoard, Chromium browser, Zoom, ViewBoard Cast
Internal Speakers
16W (x2)
HDMI 1.4 In
2
HDMI 2.0 In
1
HDMI Out
1
VGA
1
DisplayPort
1
Composite RCA
1
3.5mm Audio In
1
3.5mm Audio Out
1
SPDIF Audio Out
1
USB 3.0
2
USB 2.0
4
Slot-in PC Slot
1
USB B Touch Port
2
Ethernet LAN (RJ45)
1
WIFI Module Slot
1
Intel® OPS Slot In (80-pin)
1
Expansion Slot
1
Voltage
100-240 VAC, 50-60Hz
Consumption (max)
350W
Consumption (typical)
155W
Stand-by
<.5W
On Screen Display
Input, Volume, Backlight, Audio, Screen, Display, Adjust
Remote Control
Volume, Channel, Source, Mute, Back, Input, Menu
Temperature
32-104º F (0 - 40º C)
Humidity (non-condensing)
10-90%
Touch Technology
Infrared
Touch Points
Windows 20, Android 20
Net (lbs)
171.96
Gross (lbs)
231.49
Net (kg)
78
Gross (kg)
105
Packaging (in.)
87.0 x 53.1 x 11.0
Physical (in.)
78.3 x 46.7 x 3.9
Packaging (mm)
2211 x 1380 x 280
Physical (mm)
1988 x 1186 x 100
VESA Compatible
800 x 600 mm
Camera Mounting Bracket
1
Warranty
*Refurbished. 30-day DOA policy for full refund, with a 90-day repair warranty on parts and labor.
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Package Contents
IFP8650 display, stylus pen x 3, power cable, remote control with batteries, ViewSonic Wizard CD (User Guide), Quick Start Guide, USB cable, audio cable, camera bracket, VGA cable, power cords
Regulations
cTUVus, FCC, Mexico Energy, CE, CB, RoHS, ErP, WEEE
Classification
Refurbished
Ethernet LAN
(10/100/1000M) (Android 10/100, PC 10/100/1000)
Screen Size
86
Viewable Area (in.)
86
Light Source
LED
Display Resolution
3840 x 2160
Aspect Ratio
169
Static Contrast Ratio
1,2001
Backlight Life (Hours)
50,000
Brightness
350 cd/m2
Response Time (Typical GTG)
8ms
Viewing Angles
178º horizontal, 178º vertical
Panel Surface
Anti-glare 7H tempered glass
