Technical Specifications
Detailed technical information for this product.
Type
1RU rack mount; 19" rack
Configuration
4 power modules per shelf
Dimensions (㎜, WxLxH)
482.6 x 429.5 x 43.4 ㎜
Weight
14.25 kg (With power modules)
Input Voltage
100~120Vac / 200~277Vac
Output Voltage
48Vdc
Output Power
6000W / 100~120Vac
14000W / 200~277Vac
Efficiency
90% Min. (240Vac@25℃)
Heat Dissipation
760W/2592BTU @ 80% load
1000W/3412BTU @ 100% load
Power Redundancy
3+1 redundancy per shelf
Hot Swap
Supported for each power module
Working Temperature / Humidity
-40℃~+50℃ / 5%~95%RH
Storage Temperature / Humidity
-40℃~+85℃ / 5%~95%RH
Operating Altitude
1500m max
Audible Noise
55dbA typ, full load
Air Flow Direction
Front to rear
Lifetime
10 years (Full load, excluding fans)
Safety
60950-1, UL, CE, CB
EMC
Class A
Earthquake Requirements
Zone 4
