Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Brightness(Typ.) : 500 cd/m²
Bezel : 14.9 mm (Even, Off-Bezel)
Depth : 57.9 mm (without Handle and Logo)
Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR
Built-in Speaker(10W+10W)
Technical Specifications
Detailed technical information for this product.
Screen Size
86"
Panel Technology
IPS
Aspect Ratio
16:9
Resolution
3,840 x 2,160 (UHD)
Brightness (Typ.)
500 nits
Contrast Ratio
1,200:1
Viewing Angle (H x V)
178° x 178°
Response Time
6ms (G to G)
Surface Treatment (Haze)
Haze 3%
Life Time (Typ.)
50,000 Hrs
Operation Hours
24Hrs
Orientation
Landscape & Portrait
Input
HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
Output
DP, Audio (Off/Fixed/Variable), External Speaker (98" Only)
External Control
RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In
Bezel Color
Black
Bezel Width
14.9mm (Even, Off-Bezel)
Monitor Dimension (W x H x D)
75.8" x 43.2" x 2.4" / 1,926.2 x 1,097.2 x 60.6 mm (without Handle and Logo)
Weight (Head)
108 lbs / 49 kg
Carton Dimensions (W x H x D)
81.6" x 49.6" x 11.5" / 2,073 x 1,260 x 292 mm
Packed Weight
134.7 lbs / 61.1 kg
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Yes
Internal Memory 8GB (System 4GB + Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Image Customization, Failover, Content Sync (RS232C, Local Network), Screen Share, Play via URL, OSD Rotation, Content Rotation, PIP/PBP(4), Tile Mode Setting (Max 15x15), Setting Data Cloning, Firmware Update by Network, SNMP 1.4, ISM Mode, Crestron Connected1, Cisco Compatibility 2, Beacon, HDMI-CEC 3, SI Server Setting, webRTC
Operation Temperature
32°F to 104°F / 0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption Typ. / Max.
215 W / 280 W
Power Consumption Smart Energy Saving
151 W
Speaker
None
Safety
IEC 60950-1/EN 60950-1/UL 60950-1
EMC
FCC Class "A"/CE/KC
OPS Type Compatible
Yes
External Media Player Attachable
Yes
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Basic
Remote Controller, Power Cord, QSG, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender
Optional
Media Player, OPS Kit (KT-OPSA), Wall Mount (LSW640A/B)
Warranty
3-Year Limited Warranty
UPC
7 19192 62460 3
