Technical Specifications
Detailed technical information for this product.
Screen size (diagonal) (inch)
86-inch (2174 mm)
Screen size (diagonal) (mm)
2174 mm
Aspect Ratio
16:9
Panel Type
IPS Panel / Edge-LED
Effective display area (W x H) (mm)
1895.0 x 1065.9 mm
Effective display area (W x H) (inch)
74.6 x 41.9 inch
Resolution
3840 x 2160
Brightness (typ.)
500 cd/m2
Contrast Ratio
1200:1 (Typ)
Response Time
8 ms (G to G)
Terminals | HDMI IN
HDMI TYPE-A Connector x 2
Terminals | DisplayPort IN
DisplayPort x 1
Terminals | DisplayPort OUT
DisplayPort x 1
Terminals | DVI-D IN/AUDIO IN (L/R)
DVI-D 24-pin x 1/ Stereo Mini Jack (M3) x 2 (Shared with PC In)
Terminals | PC IN/AUDIO IN (L/R)
Mini D-sub 15-pin x 1/ Stereo Mini Jack (M3) x 2 (Shared with DVI-D In)
Terminals | USB
USB Connector (TYPE A) x 2, DC 5 V/2 A (USB 3.0 supported)
Terminals | Serial
D-sub 9-pin x 1, RS232C Compatible
Terminals | IR IN / OUT
Stereo Mini Jack (M3) x 1 / x 1
Built-in Speaker
20 W [10 W + 10 W]
Power Requirements
110-127 V AC, 50/60 Hz, 220-240 V AC, 50/60 Hz
Power consumption
480 W
Power Off Condition
Approx. 0.3 W
Stand-by Condition
Approx. 0.5 W
Dimensions (W x H x D) (mm)
1928 x 1099 x 86 mm
Dimensions (W x H x D) (inch)
75.9" x 43.3" x 3.4"
Carton Size (W x H x D) (mm)
2224 x 1427 x 373 mm
Carton Size (W x H x D) (inch)
87.6" x 56.2" x 14.7"
Bezel width (mm)
15.2 mm (T/B/L/R)
Bezel width (inch)
0.60 inch (T/B/L/R)
Operating Time
24 h/day
Operating environment
Temperature : 0 °C to 40 °C / Humidity: 20% to 80% (Non-condensation)
Weight (kg)
Approx. 66.0 kg
Weight (lbs.)
Approx. 145.5 lbs
Wall-hanging pitch (inch)
23.6˝ x 15.8˝ VESA Compliant
Viewing angle [(T/B)/(L/R)]
178°/178° (CR≧10)
Terminals | AUDIO OUT
30 W [15 W + 15 W] 10% THD
Wall-hanging pitch (mm)
600 x 400 mm VESA Compliant
Terminal | DIGITAL LINK
RJ45 x 1, 100 BASE-TX, Compatible with long reach mode and PJLink™
Terminal | LAN
RJ45 x 1, 10 BASE-T / 100 BASE-TX, Compatible with PJLink™
Operating environment | Humidity
0 °C to 40 °C (32°F to 104°F ) Altitude 0~1400 m (4593 ft)/0 °C to 35 °C (32 °F to 95 °F) Altitude 1400 ~2800 m (4593 ft to 7874 ft)
Operating environment | Temperature
20% to 80% (Non-condensation)
Orientation
Landscape/Portrait (Angle adjustment is not possible for portrait installation.)
Tilting angle
0-20 degrees forward/backward with landscape/portrait setting
Terminals | Slot
Intel® SDM specification
Corresponding size SDM-S / SDM-L, Supply power 12 V / 5.5 A, 3.3 V / 1.1 A
