Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
An Essential Way of Delivering Dynamic Content
User-Friendly Menu for Digital Signage
USB Content Scheduling & Data Cloning
Efficient Operation
A Wide Range of Interfaces
Compatibility with AV Control Systems
Detachable Logo & Built-in Speaker
Conformal Coating
Technical Specifications
Detailed technical information for this product.
Panel Size
55"
Brightness
350 nits
Native Resolution
1,920 x 1,080 (FHD)
Input
HDMI (2), DVI-D, RGB, Audio, USB
Output
Audio (Off/Fixed/Variable)
External Control
RS232C in/out, RJ45 in, IR in
Bezel Width
11.9mm (T/R/L), 18mm (B)
Monitor Dimension (W x H x D)
1,238 x 714.9 x 54 mm
Weight (Head)
17.5kg
Monitor w/opt. Stand Dimensions (W x H x D)
1,238 x 773.4 x 219.6 mm
Weight (Head + Stand)
20.8kg
Carton Dimensions (W x H x D)
1,330 x 807 x 170 mm
Packed Weight
21.7kg
VESA TM Standard Mount Interface
300 x 300 mm
External Media Player Attatchable
Yes (MP500/MP700)
OPS Type Compatible
Yes
Operating Temperature Range
0°C to 40°C
Operating Humidity Range
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-in Power
Smart Energy Saving
45.5W
Power Consumption (Typ./Max)
65W/100W
Speaker
20W (10W x 2)
Safety
IEC 60950-1/EN 60950-1/UL 60950-1
EMC
FCC Class "A"/CE/KC
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), Wi-Fi Dongle (AN-WF500), Touch Overlay (KT-T55E)
Basic
Remote Controller, Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
