Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Display content with ultra-realistic detail in vibrant colors
QMD Series SMART Signage delivers four times the FHD resolution on the same screen area, resulting in the most accura...
Read More
Enhance efficiency by displaying content from four FHD screens on a single UHD display
With the QMD Series you can deliver more information using a smaller number of units by displaying the equivalent of ...
Read More
Increase usability with flexible configurations and 16/7 operation
The QMD Series has been engineered to meet the demands of traditional commercial environments with 16/7 reliability a...
Read More
Create a streamlined display area with Samsung’s detachable SBB option
Because UHD is relatively new to the commercial market, few media players currently support UHD streaming. To meet th...
Read MoreTechnical Specifications
Detailed technical information for this product.
Diagonal Size
85"
Type
120Hz Slim Direct LED BLU
Resolution
3840*2160 (4K UHD)
Pixel Pitch(mm)
0.1625 x 0.1625 (mm)
Active Display Area(mm)
1872.0(H) x 1053.0(V)
Brightness(Typ.)
500 nit
Contrast Ratio
5000:1
Viewing Angle(H/V)
178/178
Response Time(G-to-G)
6ms(Typ.)
Display Colors
16.7M(True Display) / 1.07B(Ditherd 10bit)
Color Gamut
72%
Haze
2%
Dynamic C/R
50,000:1
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
148.5MHz
Speaker Type
Built in Speaker(15W + 15W)
RGB
D-Sub, DVI-D, Display Port 1.2 (2), Display Port 1.1 (1)
Video
HDMI (3)
HDCP
HDCP1.4 (→ support UHD 30hz)
Audio
Stereo mini Jack
USB
USB (S/W update only)
Audio
Stereo mini Jack
External Control
RS232C(in/out), RJ45
External Sensor
IR
Tuner
No
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Max[W/h]
495
Typical[W/h]
375
BTU(Max)
1687.95
Sleep mode
less than 0.5W
Off mode
less than 0.5W
Set
1903.4 x 1090.5 x 105.1
Package
2050 x 1265 x 472
Set
55.5
Package
71.4
VESA Mount (mm)
600x400
Stand Type
Foot Stand (Optional)
Media Player Option Type
SBB
Bezel Width (mm)
(Top)13.2/(Side)13.2/(Bot)19.3
Recommended Usage Hours
16/7
Operating Temperature
N/A
℃ ~
N/A
℃
Humidity
10
% ~
80
%
Key Features
UHD LFD Display
Special Features
(HW) Temperature Sensor,Pivot Display, Clock Battery(80hrs Clock Keeping), Built in Speaker(15W 2ch)
(SW) FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery, LFD Home UI, Remote F/W update (MDC, MagicInfo Server) Button Lock, DDC CI, DHCP with RJ45 MDC, Urgent Message by MDC, Hot key option, Plug&Play; (Initial Setting)
Safety
60950-1
EMC
Class A
Included
Quick Setup Guide, Warranty Card, DP cable, Power Cord, Remote Controller, Batteries
Stand
STN-L7585F (New Stand)
Mount
WMN8200SD
Specialty
Overlay Touch CY-TQ85LDA
Media Player
SBB-DA/DI (Optional)
Key Features
UHD LFD Display
Special Features
(HW) Temperature Sensor,Pivot Display, Clock Battery(80hrs Clock Keeping), Built in Speaker(15W 2ch)
(SW) FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery, LFD Home UI, Remote F/W update (MDC, MagicInfo Server) Button Lock, DDC CI, DHCP with RJ45 MDC, Urgent Message by MDC, Hot key option, Plug&Play; (Initial Setting)
Safety
60950-1
EMC
Class A
Included
Quick Setup Guide, Warranty Card, DP cable, Power Cord, Remote Controller, Batteries
Stand
STN-L7585F (New Stand)
Mount
WMN8200SD
Specialty
Overlay Touch CY-TQ85LDA
Media Player
SBB-DA/DI (Optional)
