Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
The all-new embedded media player powered by TIZEN™
The new 2016 SMART Signage that supports SSSP 4.0 allows for a stronger, faster and more stable performance than its ...
Read More
Offering robust options for content creation, scheduling and deployment tools
A key aspect of the enhanced TIZEN-based SSSP 4.0 platform, Samsung’s MagicInfo Player S4 enables users to fully leve...
Read More
Bring an end to unwanted glare and always be assured of high visibility and readability
Equipped with a non-glare frontal panel, the PHF and PMF Series displays reduce natural and ambient light interferenc...
Read More
Unlock easier and more flexible control due to a centralized infrared receiver
The standalone displays’ integrated centralized infrared receiver (IR) ensures easier and more flexible user control....
Read More
Put your worries to rest knowing that your display is protected from a range of environmental conditions
All of Samsung’s new PMF and PHF standalone displays are IP5x certified, signifying their dust-resistant design and a...
Read More
Increase content possibilities with Samsung PIMs
PHF-P series are designed to use content from various external sources including Samsung PIMs.Samsung PIMs use Intel®...
Read MoreTechnical Specifications
Detailed technical information for this product.
Diagonal Size
43"
Type
60Hz E-LED BLU
Resolution
1920*1080 (Full HD)
Pixel Pitch(mm)
0.490(H) x 0.490(V)
Active Display Area(mm)
940.89(H) x 529.25(V)
Brightness(Typ.)
700 nit
Contrast Ratio
3000:1
Viewing Angle(H/V)
178:178
Response Time(G-to-G)
8ms
Display Colors
10bit Dithering - 1.07Billion
Color Gamut
72%
Haze
44%
Dynamic C/R
Mega
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
148.5MHz
Speaker Type
Built in Speaker(10W + 10W)
RGB
DVI-I(D-Sub Common), Display Port 1.2 (2)
Video
HDMI 2.0 (2) / HDCP 2.2
HDCP
HDCP 2.2
Audio
Stereo mini Jack, RGB/DVI/HDMI
USB
USB 2.0 x 2
RGB
DP1.2(Loop-out)
Audio
Stereo mini Jack
External Control
RS232C(in/out) thru Stereo Jack, RJ45
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Max[W/h]
154
Typical[W/h]
EU108, US 108, WW 108
BTU(Max)
525.14
Sleep mode
less than 0.5W
Off mode
less than 0.5W
Set
959.7 x 550.1 x 29.9
Package
1037 x 628 x 132
Set
9.4
Package
11.4
VESA Mount (mm)
200x200
Stand Type
Foot Stand (Optional)
Bezel Width (mm)
6.9/6.9/8.9
Recommended Usage Hours
24/7
Operating Temperature
0.0
℃ ~
40.0
℃
Humidity
10.0
% ~
80.0
%
Key Features
Slim & Light Signage with Built-in MagicInfo S4, SSSP 4.0
Special Features
H/W : Non Glare Panel, Temperature Sensor, Video Wall(15x15(OSD)), Video Wall Daisy Chain(16), Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded, IP5x, Center IR
S/W : Magic Clone(to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(HDCP Support), Firmware Update by Network, New Home Screen, PC-less VideoWall(external source only), Multi Channel, Mobile Control, Event Schedule, Backup Player
Processor
Cortex-A12 1.3GHz Quad Core CPU
On-Chip Cache Memory
L1 (I/D) : 32KB / 32KB
L2 (Unified) : 1MB
Clock Speed
1.3GHz CPU Quad
Main Memory Interface
2.5GB
3 channel 96bit DDR3-933 (1866MHz)
Graphics
2D & 3D Graphics Engine
- Up to 3840x2160p. 32bpp
- Supports OpenGL ES
Storage (FDM)
8GB
(3.75GB Occupied by O/S, 4.25GB Available, )
Multimedia
Video Decoder
- MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC
- VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.
IO Ports
USB 2.0
Operating System
Tizen 2.4 (VDLinux)
Safety
CB (Europe) : IEC60950-1/EN60950-1
CCC (China) : GB4943.1-2011
PSB (Singapore ) : PSB+IEC60950-1
NOM (Mexico ) : NOM-001-SCFI-1993
IRAM (Argentina ) : IRAM+IEC60950-1
SASO (Saudi Arabia ) : SASO+IEC60950-1
BIS(India) : IEC60950-1 / IS13252
NOM(Mexico) : Tuner : NOM-001-SCFI-1993
Tunerless : NOM-019-SCFI-1998
KC(Korea) : K 60950-1
EAC(Russia) : EAC+IEC60950-1
INMETRO(Brazil) : INMETRO+IEC60950-1
BSMI(Taiwan) : BSMI+IEC60950-1
RCM(Australia) : IEC60950-1/AS/NZS 60950-1
UL(USA) : cUL60950-1
CSA (Canada) : cUL
TUV (Germany) : CE
NEMKO (Norway) : CE
EMC
FCC (USA) Part 15, Subpart B Class A
CE (Europe) : EN55022:2006+A1:2007
EN55024:1998+A1:2001+A2:2003
VCCI (Japan) : VCCI V-3 /2010.04 Class A
KCC/EK (Korea) : Tuner : KN13 / KN20
Tunerless : KN22 / KN24
BSMI (Taiwan) : CNS13438 (ITE EMI) Class A /
CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital)
C-Tick (Australia) : AS/NZS CISPR22:2009
CCC(China) :GB9254-2008
GB17625.1-2012
GOST(Russia/CIS) : GOST R 51317 Series,
GOST 22505-97
EN55022:2006+A1:2007
EN55024:1998+A1:2001+A2:2003
Included
Quick Setup Guide, Regulatory Guide , Warranty Card,
Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover Jack
Stand
STN-L3240E
Mount
WMN4070SD
Specialty
CML400XJ
Media Player
SBB,PIM
