Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Leverage powerful imagery on a compact scale
Samsung’s small-sized semi-outdoor signage provides business owners with a dynamic approach to delivering a coherent ...
Read More
Deliver promotional messaging vividly with excellent visibility
Draw more visitors to your retail business by effectively delivering promotional messaging with excellent visibility....
Read More
Rely on strong 24 / 7 durability in various outdoor environments
Present business messaging 24 / 7 even when the display is exposed to sunlight directly and indirectly for reliable a...
Read More
Manage digital signage wirelessly, virtually anywhere, anytime on a mobile device with an easy-to-use application
Simplify content control and enhance efficiency by using the MagicInfo S3 mobile application on your mobile device to...
Read More
Conveniently and simply manage a rich array of content with an advanced content management platform
Deliver myriad rich content with OM24E built-in media player and simplified management through 3rd Generation Samsung...
Read More
Display content with optimal brightness and cost-efficiency
Optimise brightness control while reducing display operating expenses and power consumption with an automatic brightn...
Read MoreTechnical Specifications
Detailed technical information for this product.
Diagonal Size
24"
Type
S-VA
Resolution
1920*1080 (Full HD)
Pixel Pitch(mm)
0.274 x 0.274
Active Display Area(mm)
525.888x295.812
Brightness(Typ.)
1500 nit
Contrast Ratio
4000:1
Viewing Angle(H/V)
178/178
Response Time(G-to-G)
8ms
Display Colors
8 bit - 16.7M
Color Gamut
72%
Haze
0%
Dynamic C/R
100,000:1
H-Scanning Frequency
60Hz
V-Scanning Frequency
67.5KHz
Maximum Pixel Frequency
148.5Mhz
Speaker Type
Mono
RGB
Analog D-SUB
Video
HDMI
HDCP
HDCP 1.4
Audio
Stereo Mini Jack
USB
USB 2.0 x 2
Audio
Stereo Mini Jack
External Control
RS232C (In), RJ45
External Sensor
Detachable Type (Ambient)
Tuner
No
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Max[W/h]
TBD
Typical[W/h]
TBD
BTU(Max)
TBD
Sleep mode
TBD
Off mode
TBD
Set
549.2 × 319.1 × 58.0
Package
651.0 × 390.0 × 139.0
Set
3.5
Package
4.8
VESA Mount (mm)
100 × 100
Bezel Width (mm)
10.5
Recommended Usage Hours
24/7
Operating Temperature
0.0 ℃ ~ 50.0 ℃
Humidity
10.0 % ~ 80.0 %
Key Features
High Brightness, Semi-Outdoor Solution Built-in MagicInfo Player S3, SSSP 3.0
Special Features
Plug and Play, MagicInfo S3, Built in Speakers, Lamp Error Detection, Anti Image Retention, Temperature Sensor, RS232C/RJ45 MDC, PIP/PBP, Auto Source Switching & Recovery, Portrait Installation Support, Button Lock, Smart Scheduling, WiFi Embedded, Sunglasses Viewable
Processor
Cortex-A9 1GHz Quad Core CPU
On-Chip Cache Memory
L1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
Clock Speed
1GHz CPU Quad
Main Memory Interface
1.5GB Dual 48bit DDR3-933 (1866MHz)
Graphics
2D & 3D Graphics Engine - Up to 1920x1080. 32bpp - Supports OpenGL ES
Storage (FDM)
8GB (2GB Occupied by O/S, 6GB Available)
Multimedia
Video Decoder - MPEG-1/2, H.264/AVC (Dual) - VC-1, JPEG, PNG,VP8 Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc.
IO Ports
USB 2.0
Operating System
Samsung Proprietary OS(VDLinux)
Safety
UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1998 IRAM (Argentina) : IEC60950-1 SASO (Saudi Arabia) : IEC60950-1
EMC
FCC (USA) : Part 15, Subpart B Class A CE (Europe) : EN55022, EN55024 VCCI (Japan) : V-3 (CISPR22) KCC (Korea) : KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC (China) : GB9254-2008, GB17625.1-201
Included
External Brightness Sensor, Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries
Key Features
High Brightness, Semi-Outdoor Solution Built-in MagicInfo Player S3, SSSP 3.0
Special Features
Plug and Play, MagicInfo S3, Built in Speakers, Lamp Error Detection, Anti Image Retention, Temperature Sensor, RS232C/RJ45 MDC, PIP/PBP, Auto Source Switching & Recovery, Portrait Installation Support, Button Lock, Smart Scheduling, WiFi Embedded, Sunglasses Viewable
Processor
Cortex-A9 1GHz Quad Core CPU
On-Chip Cache Memory
L1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
Clock Speed
1GHz CPU Quad
Main Memory Interface
1.5GB Dual 48bit DDR3-933 (1866MHz)
Graphics
2D & 3D Graphics Engine - Up to 1920x1080. 32bpp - Supports OpenGL ES
Storage (FDM)
8GB (2GB Occupied by O/S, 6GB Available)
Multimedia
Video Decoder - MPEG-1/2, H.264/AVC (Dual) - VC-1, JPEG, PNG,VP8 Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc.
IO Ports
USB 2.0
Operating System
Samsung Proprietary OS(VDLinux)
Safety
UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1998 IRAM (Argentina) : IEC60950-1 SASO (Saudi Arabia) : IEC60950-1
EMC
FCC (USA) : Part 15, Subpart B Class A CE (Europe) : EN55022, EN55024 VCCI (Japan) : V-3 (CISPR22) KCC (Korea) : KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC (China) : GB9254-2008, GB17625.1-201
Included
External Brightness Sensor, Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries
