All-in-one touch solution for any environment

QMR-T displays maximize the touch display experience with a built-in, high performance Tizen-based media player. The ...

Powerful touch experience

Upgraded Tizen OS makes playback more stable and opens up new possibilities with high-speed content. A responsive cap...

Captivate customers with UHD content

Samsung’s QMR-T series provides UHD resolution capabilities for incredibly clear content, increasing customer engagem...

Better visibility even in sunlight

SThe QMR-T series offers improved visibility through non-glare glass which removes reflections that might disturb cus...

Built to be reliable and efficient

With an IP5X rating standard, the display is guaranteed to be efficient and reliable even in dusty environments. An i...

Integrated content and device management solution

Samsung’s MagicINFO solution enables easy content creation for touch display and simple scheduling and management fro...

Diagonal Size 55"

Type Edge LED BLU

Resolution 3840*2160 (4K UHD)

Pixel Pitch(mm) 0.315 x 0.315

Active Display Area(mm) 1209.6(H) x 680.4(V)

Brightness(Typ.) 400 (with Touch glass), 500(without Touch Glass) nit

Contrast Ratio 4,000:1 (Without Glass)

Viewing Angle(H/V) 178/178

Response Time(G-to-G) 8ms(Typ.)

Display Colors 16.7M

Color Gamut 92% (DCI-P3, CIE 1976)

Operation Hour 24/7

Haze 25% (Without Glass)

Dynamic C/R MEGA

H-Scanning Frequency 30 ~ 81kHZ

V-Scanning Frequency 48 ~ 75HZ

Maximum Pixel Frequency 594MHz

Speaker Type Built in Speaker(10W + 10W)

Input / RGB DVI-D, Display Port 1.2 (1)

Input / Video HDMI 2.0 (2)

Input / HDCP HDCP2.2

Input / Audio Stereo mini Jack, DVI, HDMI

Input / USB USB 2.0 x 2

Output / RGB HDMI 2.0 (Loop-out)

Output / Audio Stereo mini Jack

Output / Usb USB Type-B x 2 (Touch Sensor Data, PC 1 / SoC 1)

External Control RS232C(in/out) thru stereo jack, RJ45

External Sensor IR

Type Internal

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption / Max[W/h] 143

Power Consumption / Typical[W/h] 107

Power Consumption / Rating[W/h] 130

Power Consumption / BTU(Max) 487.63

Power Consumption / Sleep mode 0.5

Dimension (mm) / Set 1253.8 x 734.6 x 56.7

Dimension (mm) / Package 1421 x 884 x 165

Weight (kg) / Set 26.9

Weight (kg) / Package 32.5

VESA Mount (mm) 200 X 200

Bezel Width (mm) 26.0mm(U/D), 21.0mm(L/R)

Operating Temperature 0 ℃ ~ 40 ℃

Humidity 10 % ~ 80 %

Key Features UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0, Cap touch

Special Features H/W: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), IP5x Rating, Wi-Fi/BT S/W: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)

Internal Player / Processor Cortex A72 1.7GHz Quad-Core CPU

Internal Player / On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Internal Player / Clock Speed 1.7GHz

Internal Player / Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bit

Graphics Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

IO Ports USB 2.0

Operating System Tizen 4.0 (VDLinux)

Safety 60950-1

EMC Class B

Security 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP

Included Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries

Optional / Stand STN-L4355F

Optional / Mount WMN4070SE

Optional / Specialty CML400XK
