Samsung

QM-F Series 85"

Call for price
With stunning 4K UHD quality our QM-F Series commercial displays provide high pixel density, fine detail and exceptional stopping power. All with multi-screen support and reliable 24/7 continuous use to meet around the clock operating requirements from retail spaces and...
Request a Quote
100% Satisfaction
Guaranteed
Quick & Easy
Returns Policy
Always Get
Our Best Price

SKU: LH85QMFPLGC/ZA

MFG Part: LH85QMFPLGC/ZA

Technical Specifications

Free shipping on orders over $500.

30-day return policy for unopened items.

Contact us for warranty claims and support.

Proudly partnered with:

Built for Commercial Excellence

Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.

Multi-Screen Delivers Multiple Messages

Multi-Screen Delivers Multiple Messages

The Picture by Picture function allows you to display up to 4 content feeds at once, each supporting Full HD 1080p re...

Read More
Non-Glare Panel for Improved Visibility

Non-Glare Panel for Improved Visibility

The non-glare panel features 500nit brightness to improve visibility of your message.

Reliable 24/7 Around the Clock Operation

Reliable 24/7 Around the Clock Operation

Innovative Samsung cooling technologies allow your message to be displayed with highly reliable 24/7 continuous opera...

Read More
Stunning 4K UHD Picture Quality

Stunning 4K UHD Picture Quality

3840 x 2160 UHD resolution (4x the number pixels of Full HD 1080p) delivers life-like image quality. Experience a hig...

Read More
Impactful 85" Screen

Impactful 85" Screen

The QM85F features a big, beautiful 85" UHD panel, for engaging images and messages that cannot be ignored. Imagine t...

Read More
Consumer TVs vs. Commercial Displays

Consumer TVs vs. Commercial Displays

See how commercial displays specifically designed for business environments deliver key benefits that are missing fro...

Read More
The Ins and Outs of Digital Signage

The Ins and Outs of Digital Signage

Learn what's required to install, maintain and manage a video display implementation, so you can consider digital sig...

Read More
1897 Market by HMSHost

1897 Market by HMSHost

Learn how HMSHost worked with Samsung and OSM Solutions to deploy digital signage throughout this restaurant at Charl...

Read More

Technical Specifications

Detailed technical information for this product.

Series Name QM85F
Screen Size 85"
Panel Technology 120Hz Slim Direct LED BLU
Resolution 3840x2160
Aspect Ratio 16:9
Brightness 500nit
Contrast Ratio (Typical) 5000:1
Contrast Ratio (Dynamic) Mega
Viewing Angle (H/V) 178/178
Response Time 6ms
Input RGB: D-Sub, DVI-D, Display Port 1.2 (2), Display Port 1.1 (1) VIDEO: HDMI 1.4 (3) HDCP: HDCP1.4 (support UHD 30hz) AUDIO: Stereo mini Jack, RGB, DVI, HDMI USB: (S/W update only)
Output Audio: Stereo Mini Jack
External Control RS232C(in/out), RJ45
Sensor IR
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 368W (Typical) / 495W (Max)
Power Consumption (Standby) less than 0.5W
Operating Temperature 0℃~ 40℃
Operating Humidity 10~80%
Special HARDWARE: Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock Keeping), Built in Speaker (15W 2ch), Videowall (15x15) (OSD) SOFTWARE: FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery, LFD Home UI, Button Lock, DDC CI, DHCP with RJ45 MDC, Urgent Message by MDC, Hot key option, Plug&Play (Initial Setting)
Plug & Play Yes (Initial Setting)
24/7 Operation Yes
Built-in Speakers Built in Speaker(15W + 15W)
Without Stand (W x H x D) 74.9" x 43.1" x 4.1"
Packaging (W x H x D) 80.72" X 49.8" X 18.58"
Bezel Width 13.2mm ( Top / Side) / 19.3mm (Bott
Product Weight 110.45 lbs
Package Weight 147.49 lbs
Standard Warranty 3yr Onsite (Parts/Labor/Backlight)
Included in Box uick Setup Guide, Warranty Card, DP cable, Power Cord, Remote Controller, Batteries
Optional Wall Mount Kit WMN8200SD
Optional Media Player SBB-DA/DI
RoHS Compliant Yes
Emission Standard EMC Class A
Packaging Recyclability Packing Materials Recyclable
VESA Mount 600x400
Operating Temperature 0℃~ 40℃
Operating Humidity 10~80%
