Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Technical Specifications
Detailed technical information for this product.
Series Name
QBR Series
Screen Size
13"
Panel Technology
Edge LED
Resolution
1920 x 1080
Brightness
300 nit
Contrast Ratio (Typical)
800:1
Contrast Ratio (Dynamic )
MEGA
Viewing Angle (H/V)
178/178
Response Time
8ms (Typ.)
Operation Hours
16/7
Input
VIDEO: HDMI 1.4 (1) HDCP: HDCP 2.2 USB: USB 2.0 (1)
Output
AUDIO: Stereo Mini Jack
External Control
RS232C(in) thru stereo jack, RJ45
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max)
Typical: 13 W/h Max: 27.5 W/h
Power Consumption (Standby)
0.5
Operating Temperature
0℃~ 40℃
Operating Humidity
10~80%
Key
Small Signage Display, Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
Special
HARDWARE: Temperature Sensor, Pivot Display, Clock Battery (168hrs Clock Keeping), Built in Speaker (5W 1Ch), IP5x Rating, Wi-Fi SOFTWARE: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot Key Option, Plug&Play (Initial Setting)
SMART Signage Platform
Yes
Plug & Play
Yes
Wi-Fi
Yes
Speaker Type
Built in Speaker (5W)
Processor
Cortex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory
L1 Instruction Cache: 48KB L1 Data Cache: 32KB L2 Cache: 2MB
Clock Speed
1.7GHz
Main Memory Interface
2.5GB LPDDR4 1.5GHz 64bit
Graphics
Graphic Resolution: 1920 x 1080 Output Resolution: 3840 x 2160 (Scale Up From Graphic Processing Result)
Storage
8GB (3.88GB Occupied by O/S, 4.12GB Available)
Multimedia
Video Decoder: MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, HEVC, JPEG, PNG, VP8, VP9 Audio Decoder: AC3 (DD), MPEG
IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Without Stand (W x H x D)
12.68" x 7.62" x 1.11" / 322 x 193.5 x 28.2 mm
Packaging (W x H x D)
14.8" x 5.2" x 9.76" / 376 x 132 x 248 mm
Bezel Width
12.2mm
Product Weight
1.98 lbs. / 0.9 kg
Package Weight
3.75 lbs. / 1.7 kg
Included in Box
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries, Bar Type Simple Stand
Optional Stand
Bar Type Simple Stand (In Box)
VESA Mount
100 X 100
