Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Pro:Centric® Smart IPTV Platform
Embedded Pro:Idiom® decryption for non-Pro:Idiom TV's
IP Streaming and RF Tuning
Supports Ultra HD/4K (3840 x 2160) and Full HD (up to 1080p) output resolutions
Pro:Centric Application Support for non-Pro:Centric TVs
Pro:Centric® Smart IPTV Platform
Embedded Pro:Idiom® decryption for non-Pro:Idiom TV's
IP Streaming and RF Tuning
Supports Ultra HD/4K (3840 x 2160) and Full HD (up to 1080p) output resolutions
Pro:Centric Application Support for non-Pro:Centric TVs
Technical Specifications
Detailed technical information for this product.
Analog
Yes (NTSC)
Digital
Yes
Terrestrial
ATSC
Cable
Clear QAM/VSB
Triple XD Engine
Yes
Output Resolution
720p / 1366*768 1080p / 2160p
Clear Voice II
Yes
Optical Sound Sync
YES (SPDIF)
Wireless Sound Sync
Yes
Pro:Centric
Yes (Smart)
Hybrid Streaming (IP & RF) MultiCast/HTTP Data Carousel
Yes
RF (1/2Tuner)
Yes (1 Tuner )
HCAP (GEM/FLASH/HTML) Service Carousel (TLX)
GEM / Flash / HTML
HCAP Input Device Driver Support
Yes (USB Mouse, USB Keyboard, Magic Remote, USB Camera, Remote App)
Auto Configuration
Yes (EZ-Manager)
Remote Diagnosis
Yes (IP)
Multicast/Unicast Ready
Yes
IP Streaming
Yes (RTSC, HLS, SNMP, UDP/MultiCast, USB Port/Video Streaming support (Smartshare) (IGMPv3 SSM Support)
Commercial Smart UX (Smart Home / Input)
Yes
Commercial Smart Home
Yes
Third Party Embedded Apps
Yes
Web Browser option
Yes
Magic Remote
Yes (Ready)
Remote App Compatibility
Yes
Smart Share
Yes
DLNA (Movie/Photo/Music)
Yes (Smart share)
WiDi (PC to TV)
Yes
Miracast (Mobile to TV)
Yes (Smart mirroring)
Wi-Fi Direct
Yes
DIAL
Yes
HDMI-CEC
Yes
HTNG CEC
Yes
Pro:Idiom
Yes
Multi DRM
Yes (Embedded Apps)
Instant ON
Yes
WOL/WoWLAN
Yes
Wi-Fi
Yes (Built-in type)
Soft AP
Yes
Installer Menu
Yes
IR Pass Through
Yes (MPI Jack/RS232)
Audio Line Out (3Pin Phone Jack)
Yes
RJP Interface
Yes (HDMI)
RJP Compatibility
Yes (Teleadapt, G-Link)
USB
USB2.0
Moving Picture Playback (SD/HD/Plus HD)
Yes (Except Divx)
JPEG
Audio Codec
AC3 (Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
USB Cloning
Yes
One Channel Map / Logical Channel Map
Yes (LCM)
Multi IR Code
Yes
Auto Off / Auto Sleep
Yes
Video Mute
Yes
Smart Energy Saving (Auto Power Off)
Yes
External Hardware Module Interface
Yes (60pin Interface)
USB (2.0)
Yes (2)
PTC Service (3Pin Phone Jack)
Yes
External IR (3Pin Phone Jack)
Yes
Audio Line Out (3Pin Phone Jack)
Yes
Digital Audio Out (Optical)
Yes
Tuner
Yes
LAN Port
Yes
HDMI Out
Yes
TV Display Control MPI/MTI (RJ12)
Yes
TV Display Control RS-232 (4 pin phone jack)
Yes
HDMI (1,2)
Yes
AV In (4Pin Phone Jack)
Yes
AC Adaptor
Yes
Cables
HDMI, MPI, RS232 (Phone to RS232C) AV gender
Manual
Yes
Voltage, Hz
Input: AC100 ~ 240V, 50/60Hz, 1.6A Output: DC19V, 3.42A
Stand-by
0.5W
Consumption (Typical)
14.1W
EMC
FCC
Weight (Packing)
3.9 lbs
Unit Dimensions (W × H × D)
8.2" x 6.7" x 1.2"
W x H x D (Carton)
14.2" x 5.4" x 8.1"
Unit Weight
1.4 lbs
Temperature
0o C to 40o C (32o F to 104o F)
Humidity
Less than 80%
Warranty
2 Year Limited Warranty (Parts and Labor)
UPC
7 19192 91972 3
