Technical Specifications
Detailed technical information for this product.
Viewable Image Size
70"
Native Resolution
1920 x 1080
Pixel Pitch
0.8mm
Backlight Type
LED Edge-lit
Brightness (typical)
360cd/m2
Brightness (maximum)
450cd/m2
Contrast Ratio (typical)
4000:1
Response Time(Gray to Gray)
8ms
Refresh Rate
60Hz
Aspect Ratio
16:9
Active Screen Area
60.6 x 34.1in. / 1538.9 x 865.6mm
Orientation
Landscape
Displayable Colors
More than 16.7 million
Horizontal (Analog/Digital)
15.625 / 15.734 / 31.5-91.1 kHz
Vertical
50-85 Hz
Video
Analog RGB 0.7 Vp-p/75 Ohms Digital TMDS / DisplayPort
Sync
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)
PC Signal Compatibility
Yes
Macintosh Compatibility
Yes
Digital
DisplayPort, HDMI (2), DVI
Analog
VGA 15-pin D-sub
Audio
Audio Mini-Jack x 2
External Control
Ethernet (RJ45), RS-232C
Audio
Audio Mini-Jack, External Speaker Jack (2)
On
150W
ECO Mode Standby
<2.5W
Bezel Width (Left/Right, Top/Bottom)
0.9/0.9, 0.9/0.9 in. / 23.0/23.0, 23.0/23.0 mm
Net (with stand)
62.5 x 37.7 x 23.9 in. / 1587.0 x 956.8 x 606 mm
Net (without stand)
62.5 x 36.2 x 3.4 in. / 1587.0 x 919.6 x 86.9 mm
Shipping
68.4 x 45.4 x 12.5 in. / 1738 x 1153 x 318 mm
Net (with stand)
113.5lbs / 51.6 kg
Net (without stand)
103.4lbs / 47.0 kg
Shipping
134.2lbs / 61 kg
Operating Humidity
20-80%
Operating Altitude
9843 ft. / 3000m
Storage Humidity
10-90%
Storage Altitude
40,000 ft. / 12,192m
NEC
Table Top Stand (ST-801)
Optional Side-Mounted 15W Speakers (SP-TF1)
Optional Rear-Mounted 15W Speakers (SP-RM1)
Optional Tilt Wall mount (WMK-6598)
