Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
LG OLED Wallpaper Signage
Perfect Black
Perfect Color
Perfect Viewing Screen
Perfect Design
Hide in Plain Sight
N×N Expandable Screen Size
LAN Daisy Chain Management
Wall Fixers Optimized for Simple Tiling
Enhanced Flexibility of Cables
Technical Specifications
Detailed technical information for this product.
Screen Size
55"
Native Resolution
1,920 x 1,080 (FHD)
Panel Technology
OLED
Response Time
1 ms (G to G), 8 ms (MPRT)
Brightness
400/150 nits (APL 25%/100%) * Average Picture Level
Viewing Angle (H x V)
178 x 178
Surface Treatment
Hard Coating (2H), Anti-reflection Treatment of the Front Polarizer (Reflectance Typ. 1.2%)
Orientation
Portrait & Landscape
Lifetime (Typ.)
30,000 hrs
Operation Hours
12 Hrs / 7 Days (Moving Video Only)
Input
HDMI, DP, USB 2.0 (2)
Output
DP, Audio
External Control
RS232C In/out, RJ45 (LAN) In/out, IR In
Bezel Color
Black
Bezel Width
0.9 mm (Even) * Off-Bezel 5.3 mm (T/L/R),11.0 mm (B) * On-Bezel
Dimensions (W x H x D)
(Head) 48" x 27.4" x 0.2" / 1220.3 x 696.8 x 4.9 mm (Signage Box) 30.8" x 9.4" x 1.4" / 782.8 x 238.4 x 34.7 mm
Weight
22 lbs / 10 kg (Set)
Dimensions (Carton) (W x H x D)
53.1" x 33" x 9.8" / 1,350 x 837 x 250 mm
Packed Weight
50.5 lbs / 22.9 kg
Yes
Internal Memory (64GB), Temperature Sensor, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Fail Over, Content Sync (RS232C, Local Network), OSD Rotation, Tile Mode Setting, Setting Data Cloning, Firmware Update by Network, SNMP, ISM Mode, Control Manager, Crestron Connected1), DPM, PM Mode, Wake on LAN, Power on Delay, HDMI-CEC2), SI Server Setting, webRTC
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
Yes / No
Operating Temperature Range
32°F ~ 104°F / 0°C ~ 40°C
Operation Humidity Range
10% to 80%
Power Supply
100–240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ/Max)
309 W / 318 W * 8 Color Bar Based
Basic
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixers, Wall Fixer Install Guide, Install Guide Sheets, Tapes (for Cabling and Dust Proof), Screws
External Media Player Attachable
Yes
OPS Type Compatible
No
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control+/Control
Warranty
3-Year Limited Warranty
UPC
7 19192 62402 3
