SKU: IW008R

MFG Part: IW008R

Free shipping on orders over $500.

30-day return policy for unopened items.

Proudly partnered with:

Experience Greatness

The Wall is a new generation of display technology delivering a truly exclusive experience. Unparalleled in its visua...

Black Seal Technology

The fusion of an exceptionally black base with specialized Black Seal Technology, delivers pure black levels for unpa...

Ultra Chroma Technology

The Wall’s Ultra Chroma Technology produces vibrant, yet natural colors for a true-to-life visual experience. A narro...

Quantum Processor Flex

The Wall’s AI upscaling technology, powered by the Quantum Processor Flex, creates visual innovation with no boundari...

Total UX

Going beyond the traditional viewing platform, The Wall becomes a digital canvas to showcase various forms of media. ...

Ambient Mode

My W Edition/Background ThemePreset and customizable wall templates with Samsung original wall backgroundsDécor/Natur...

Infinity design

The Wall seamlessly blends into its surroundings with a slim, bezel-less design. Furthermore, The Wall’s frame featur...

Total ecosystem

Designed for a seamless full-scale experience, The Wall synchronizes harmoniously with various elements of a luxury e...

Pixel Pitch 0.84mm

Pixel Configuration 1 red, 1 green, 1 blue

Configuration (LxH, per cabinet) 960x540 pixels

Diode Type Flip-chip RGB LED

Dimensions (W x H x D, Cabinet) 806.4x453.6x29.9 mm

Dimensions (inch, inchxD, per cabinet) 36.4x1.2 inch

No. of Modules (WxH, per cabinet) 4 x 3

Weight (per cabinet/per ㎡) 11.5Kg / 31.4Kg

Processor Quantum processor Flex

Brightness (Peak/Max) 2,000 nit / 250 nit

Contrast Ratio 30,000 : 1

HDR Compatibility LED HDR, HDR10+ Support

Viewing angle - Horizontal 155°

Viewing angle - Vertical 135°

Bit Depth 16 bit (Internal processing 20bit)

Calibration D Gamma / Pixel to Pixel / Module to Module / Quality Mode

Color Temperature - Default 8,500K+-1,000K(floating Bin)

Color temperature - Adjustable 6,500K~10,000K (use M/BOX)

Video Rate 100/120 Hz

Input Power Range 100~240 VAC, 50/60 Hz

Power consumption - Max 465 (W/㎡) / 170 (W/Cabinet)

Power consumption - Typical 410(W/㎡) / 150 (W/Cabinet)

Heat Generation - Max 580 (BTU/Cabinet) / 1,586 (BTU/m²)

Heat Generation - Typ 512 (BTU/Cabinet) / 1,400 (BTU/m²)

Refresh rate 3,840 Hz

Working Temperature / Humidity 0°C~+40°C / 10%~80%RH

Storage Temperature / Humidity -20°C~+45°C / 5%~95%RH

IP Rating IP20

LED Lifetime 100,000 hours

Connectivity Optical ※ HDBT is used for connecting only BT/Wifi module

Sensor Ambient Light / Temperature

Smart TV type Smart

Smart Function Entertainment Mode, Ambient Mode, Apps (Netflix, YouTube, Apple TV, etc.), Bixby (Voice), SmartThings (IoT)

Bixby Language US English, Korean, UK English, French, German, Italian, Spanish (features vary by language)

Certification EMC Class B, Safety 60950-1

Service Front

Box Dimension (WxDxH) 940 x 587 x 162

Box Volume (m3) 0.089

Package Weight (kg, per cabinet) 16.1 kg

Smart Function Entertainment Mode, Ambient Mode, Apps (Netflix, YouTube, Apple TV, etc.), Bixby (Voice), SmartThings (IoT)

Accessories Décor Frame (Standard), Frame Kit ※ Provide Décor Frame Customizable Guide

Remote Control Tablet App, Smart Control

Disclaimer Peak value according to IDMS (Information Display Measurement Standard)

Disclaimer Measured under 10lux light. Contrast in darkroom exceeds 1000000:1
