CDE7530 - 75 Display, 3840 x 2160 Resolution, 450 cd/m2 Brightness, 24

Home
CDE7530 - 75 Display, 3840 x 2160 Resolution, 450 cd/m2 Brightness, 24/7

Request a Quote

100% Satisfaction
Guaranteed

Quick & Easy
Returns Policy

Always Get
Our Best Price

SKU: CDE7530

MFG Part: CDE7530

Free shipping on orders over $500.

30-day return policy for unopened items.

Proudly partnered with:

Multiple Ways to Connect and Share

Connect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software a...

AV Control System Interoperability

These displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins a...

Centralized Device Control Manager

For IT admins, it’s tough managing the hundreds of devices and displays that live on the network. Now with myViewBoar...

Easy Content Sharing

myViewBoard™ Display is a cloud-based and client-free app that allows you to share your screen from anywhere in the w...

Superb and Stunning Picture Quality

With 4K resolution, high brightness and 25% high haze anti-glare glass treatment, these displays deliver bright, clea...

Powerful Secured Embedded Platform

This display can execute several tasks at once while providing smooth content playback without the need for a PC or m...

OS Android 11.0

Media Player Type Media Player

GPU G52MP2

CPU Amlogic T982 / 1.9GHz CPU

CPU Processor Speed Quad-core, 1.5GHz

Memory 4GB DDR4

Storage 32GB

Built-in Software HTML5, JavaScript and CSS

Internal Speakers 10W (x2)

HDMI 2.1 (HDCP 2.2) In 3

Audio-out (HDMI ARC) 1

HDMI 2.0 Out 1

SPDIF Audio Out 1

USB 3.0 1

USB 2.0 1

USB Type C 1

RS232 1

Ethernet LAN (RJ45) 1

WIFI Module Slot 1

Intel® OPS Slot In (80-pin) 1

Voltage 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz

Consumption (max) 415W

Consumption (typical) 235W

Stand-by <0.5W

Temperature 32-104º F (0 - 40º C)

Humidity (non-condensing) 20-80%

Net (lbs) 56.0

Gross (lbs) 73.3

Net (kg) 25.4

Gross (kg) 33.3

Packaging (in.) 73.35 x 42.91 x 8.86

Physical (in.) 66.36 x 37.94 x 3.21

Packaging (mm) 1863 x 1090 x 225

Physical (mm) 1685.6 x 963.7 x 81.6

VESA Compatible 800 x 600 mm

Screw Size M8

Screw Length (mm) 25

AV Control AMX Certified, Extron Certified, Crestron Connected

Warranty Three-year limited warranty on parts, labor and backlight

Recycle/Disposal Please dispose of in accordance with local, state or federal laws.

Package Contents CDE7530 Wireless Presentation Display, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount Screws and RS232 cable

Regulations cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy

Ethernet LAN 10/100/1000 MB

Wifi Optional VB-WIFI-001

Bluetooth Optional VB-WIFI-001

Display Type LCD

Screen Size 75

Viewable Area (in.) 75

Orientation Landscape / Portrait

Colors 1.07B

Color Space Support 8 bit + FRC

Light Source DLED

Display Resolution 3840 x 2160

Refresh Rate 60Hz

Panel Type ADS

Aspect Ratio 169

Static Contrast Ratio 1,2001

Dynamic Contrast Ratio 5,0001

Backlight Life (Hours) 50,000

Brightness 450 cd/m2

Response Time (Typical GTG) 8ms

Bezel Width (in.) 0.59 (uniform)

Bezel Width (mm) 15 (uniform)

Viewing Angles 178º horizontal, 178º vertical

Panel Surface Anti-Glare type, Hard-coating (3H), Haze 25%

Operation Rating 24/7

CDE7530 - 75 Display, 3840 x 2160 Resolution, 450 cd/m2 Brightness, 24/7

Built for Commercial Excellence
