Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Artistic Space Beyond Display
Perfect Black
Perfect Color
Perfect Viewing Screen
Perfect Design
Hide in Plain Sight
N×N Expandable Screen Size
LAN Daisy Chain Management
Wall Fixers Optimized for Simple Tiling
Enhanced Flexibility of Cables
Technical Specifications
Detailed technical information for this product.
Screen Size
65"
Native Resolution
3,840 x 2,160 (UHD)
Panel Technology
OLED
Response Time
1 ms (G to G), 8 ms (MPRT)
Brightness
400/150 nits (APL 25%/100%) * Average Picture Level
Viewing Angle (H x V)
178 x 178
Surface Treatment
Hard Coating (2H), Anti-reflection Treatment of the Front Polarizer (Reflectance Typ. 1.2%)
Orientation
Portrait & Landscape
Lifetime (Typ.)
30,000 hrs
Operation Hours
12 Hrs / 7 Days (Moving Video Only)
Input
HDMI, DP, USB 2.0 (2)
Output
DP, Audio
External Control
RS232C In/out, RJ45 In/out, External IR Receiver
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
Yes / No
Bezel Color
Black
Packed Weight
51.6 lbs / 23.4 kg
Bezel Width
(Off bezel) 0.9 mm (Even) (On bezel) 8.1 mm (T), 10.7 mm (B), 8.3 mm (L/R)
Dimensions (Carton) (W x H x D)
62.6” x 38.0” x 8.1” / 1,590 x 965 x 205 mm
Dimensions (W x H x D)
(Head) 56.9” x 32.4” x 0.2” / 1,445.1 x 822.6 x 6.0 mm (Signage Box) 29.7” x 9.4” x 1.4” / 754 x 239 x 35.5 mm
Weight
29.8 lbs / 13.5 kg (Set)
Operating Temperature Range
32°F ~ 104°F / 0°C ~ 40°C
Operation Humidity Range
10% to 80%
Power Supply
100–240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ/Max)
440 W (8 color bar) / 478 W (8 color bar)
Yes
Internal Memory (64GB), Temperature Sensor, webOS 3.0+, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Fail Over, Content Sync (RS232C, Local Network), OSD Rotation, Tile Mode Setting, Setting Data Cloning, Firmware Update by Network, SNMP, ISM Mode, Control Manager, Crestron Connected(1) DPM, Energy Saving, PM Mode, Wake on LAN, Power on Delay, HDMI-CEC2), SI Server Setting, webRTC
External Media Player Attachable
Yes
OPS Type Compatible
No
Basic
Remote Controller (2ea Batteries Included), Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (1,150mm x 4ea for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable)
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control+/Control
