Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Vitalize True Colors of UHD Content in a Smart Way
Superior Picture Quality
Easy Content Management
Simple Group Management
Various Sensor Applications
Multi Screen Mode
Real-Time Monitoring & Control
Real-time Care Service
Wireless Solution
Wireless Access Point
Compatibility with AV Control System
Compatibility with Video Conference System
Slim and Tidy in Appearance
Detachable Logo
Technical Specifications
Detailed technical information for this product.
Screen Size
98"
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
3,840 x 2,160 (UHD)
Brightness(Typ.,cd/m²)
350
Contrast Ratio
1,300:1
Dynamic CR
500,000:1
Viewing Angle (H x V)
178 x 178
Response Time
8ms (G to G)
Surface Treatment (Haze)
Haze 1%
Life Time (Typ.)
50,000 Hrs
Operation Hours
24 Hrs
Orientation
Landscape & Portrait
Input
HDMI (3), DP, DVI-D, Audio, USB (2)
Output
DP, Audio, External Speaker
External Control
RS232C In/out, RJ45 (LAN) In, IR In
Bezel Color
Black
Bezel Width
14.9 mm (Even)
Monitor Dimension (W x H x D)
2,191.8 x 1,246.8 x 69.4 mm (without Handle)
Weight (Head)
88 kg
Carton Dimensions (W x H x D)
2,342 x 1,386 x 402 mm
Packed Weight
123 kg
Handle
Yes
VESA™ Standard Mount Interface
800 x 400 mm
Operation Temperature Range
0°C to 40°C
Operation Humidity Range
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Typ. / Max.
315 W / 415 W
Smart Energy Saving
220.5 W
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
N/A / N/A
External Media Player Attachable
Yes
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control+/Control
Basic
Remote Controller, Power Cord, QSG, IR/Light Sensor Receiver, DP Cable, Regulation Book, Phone to RS232C Gender, EYE-BOLT
Optional
Speaker (SP-2200)
