Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Interactive Display That Creates Collaboration
Multi Touch & Writing
Palm erasing
Air Class
Screen Sharing
Built-in OPS Slot
Web browser
All-in one
High Resolution Clarity with Ultra HD
True Color, Immersive View
Technical Specifications
Detailed technical information for this product.
Screen Size
86
Panel Technology
IPS
Back Light Type
Direct
Native Resolution
3,840 x 2,160 (UHD)
Brightness(Typ., cd/m², w/ Protection Glass)
330
Contrast Ratio
1,100:1
Viewing Angle (H x V)
178 x 178
Response Time
8ms(G to G)
Life Time (Typ.)
30,000 Hrs (Min.)
Operation Hours
16Hr
Orientation
Landscape
(Input) Video / Audio
HDMI (3), RGB / Audio In
(Input) External Control
RS232C In, RJ45
(Input) USB
USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2)
(Output) Video / Audio
HDMI (1), Optical Output / Audio Out
Bezel Color
Black
Bezel Width(Off Bezel)
Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D)
1,957×1,160×86mm
Weight (Head)
67kg
Carton Dimensions(W x H x D) with pallet
2,230×1,499×285mm
Packed Weight
109kg
Handle
Yes
VESA™ Standard Mount Interface
800 x 600
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240 V~, 50/60 Hz
Power Type
Built-In Power
Power Consumption (Typ. / Max.)
365W / 419W
Speaker
Built in 24W (12W + 12W)
Safety
CB / NRTL
EMC
FCC Class "A" / CE
ErP / Energy Star
Yes (EU Only) / N/A
OPS Type Compatible
Yes
Basic
Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
Embedded Writing Software
Yes
Touch type
IR
Available object size for touch
Ø3 mm ↑
Response Time
60ms ↓ (Android) / 100ms ↓ (Windows)
Accuracy
1.5mm
Interface
USB 2.0
Protection Glass Thickness
4T (Anti-Glare)
Protection Glass Transmission
87%
Operating System Support
Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point
Max 20 points / Max 10 writing
