Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Create Collaboration with this Interactive Touch Display
In-Cell Touch
Active Pen
Data Mirroring
Screen & File Sharing
Interactive UX-UI
All-in one
USB-C Type Ready
True Color, Immersive View
Vivid Color Details with Ultra HD
LG C-Display+ Customer App
Technical Specifications
Detailed technical information for this product.
Screen Size
85.6
Panel Technology
IPS
Back Light Type
Edge
Native Resolution
3,840 x 2,160 (UHD)
Brightness(Typ., cd/m², w/ Protection Glass)
350
Contrast Ratio
1,000:1
Viewing Angle (H x V)
178 x 178
Response Time
8ms (G to G)
Life Time (Typ.)
50,000 Hrs
Operation Hours
16Hr
Orientation
Landscape
Video / Audio
HDMI (3), DP, DVI-D, USB
External Control
RS232C In/Out
USB
USB 2.0 (2), USB Type C(USB2.0), Touch Out(USB2.0,B Type)(2)
Bezel Color
Black
Bezel Width
(T/L/R/B) set: 28.8mm
Monitor Dimension (W × H × D)
1952.6 X 1164.1 X 86.4mm
Weight (Head)
66.7 kg
Carton Dimensions (W × H × D)
2190 X 1470 X 371mm
Packed Weight
96.4kg
Handle
Yes
VESA™ Standard Mount Interface
600 x 400
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100 ~ 240V, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ. / Max.)
360W / 420W
Speaker
Built in(10W/Ch)
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
OPS type compatible
Yes
optional
(OPS Kit (KT-OPSF))
Basic
Remote Controller, Power Cord, QSG, HDMI(3M), Regulation Book, Phone to RS232C Gender, Touch Pen(2ea, include battery 2ea), Pen Tip(12ea), Tip Remover(2ea), USB Type-C Cable, Ferrite Core Filter
IDB App
Yes
Touch type
In-cell
Available object size for touch
Ø5 mm ↑
Reponse Time (PC Windows 10)
70ms↓
Accuracy
1.5mm
Interface
USB 2.0
Protection Glass Thickness
1.85T (Anti-Glare)
Protection Glass Transmission
88%
Operating System Support
Win7 professional, Win8.1, Win10
Multi touch point
Finger : Max 20 Point (Windows), Finger: Max 10Point (webOS), Active Pen : Max 2 Point
