Technical Specifications
Detailed technical information for this product.
Screen Size
86" class (TBD") diagonal
Brightness
Typ: 500cd/m2, Min : 400cd/m2
Life time
50,000 Hrs
Viewing Angle(H x V)
178 x 178
Dynamic CR
500,000:1 (Typ) : TBD
Contrast Ratio
1,100:1(Typ)
Response Time
8ms (G to G BW) typ.
Surface Treatment
AGP (10% Haze)
Orientation
Landscape / Portrait
Panel Technology
IPS
Aspect Ratio
58:9
Native Resolution
3,840 x 600 (UHD)
Basic
Remote Controller (2ea Batteries included), Power Cord, DP (3M), RS-232C Cable (3M) Owner's Manual (Website upload)
Optional
AN-WF500 (WiFi USB Dongle), MP700, KT-OPSA (OPS KIT), KT-SP0 (RGB Sensor) ** Stand is not available
OPS type compatible
Yes
External Media player Attachable
No
Bezel Color
Black
VESA TM Standard Mount Interface
200mm x 600mm
Packed Weight
78lbs
Carton Dimensions (W x H x D)
90.2" x 9" x 18.9"
Weight (Head)
45.2lbs
Bezel Width
4.4mm (L/R), 5.9mm (T/B)
Monitor Dimension (W x H x D)
85" x 13.7" x 3.2"
Input
HDMI, DP, OPS, DVI-D, USB2.0, USB3.0, SD Card
External Control
RS232C, RJ45, IR+B Receiver, Pixel Sensor, Analog Audio
Output
Analog Audio
UPC
TBD
Yes
Temperature Sensor, Auto Brightness Sensor, Tile Mode, Natural Mode@Tile Mode, ISM Method, Energy Saving, Smart Energy Saving, File Play with USB/SD/Internal Memory, PIP/PBP, 8GB (System 4GB + Available 4GB), Wi-Fi Dongle Ready, 4K Up Scaling
Power Consumption Smart Energy Saving
30% of typical
Power Consumption Typ. / Max.
180W/220W
Power Supply
100 -240V~, 50/60Hz
Power Type
Built-In Power
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KC
SuperSign C
Yes
SuperSign W/Lite
Yes
Warranty
3-Year Limited Warranty (Parts and Labor) | Extended Warranties Available
