Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Ships with ATSC digital tuner (SB-11TM) allows for high-definition broadcast capabilities
Full bi-directional external control via both RS232 and LAN
Expanded terminal interface including 2 HDMI, DisplayPort, DVI and VGA connections
Full 3 year commercial grade warranty
Model includes anti glare screen allowing customers maximum visibility of the content displayed on the screen
Technical Specifications
Detailed technical information for this product.
Panel Technology
UV²A
Viewable Image Size
70 "
Aspect Ratio
16:9
Native Resolution
1920x1080
Pixel Pitch
0.8 mm
Backlight Type
LED Edge-lit
Brightness (typical)/Brightness (maximum)
360 cd/m, 2, 450 cd/m, 2
Contrast Ratio (typical)
4000:1
Viewing Angle (typical)
176° Vert., 176° Hor. (88U/88D/88L/88R) @ CR>10
Response Time (Gray to Gray)
8 ms
Refresh Rate
60Hz
Active Screen Area
60.6 x 34.1in. / 1538.9 x 865.6mm
Orientation
Landscape
Displayable Colors
More than 16.7 million
Horizontal (Analog/Digital)
15.625 / 15.734 / 31.5-91.1 kHz
Video/Sync
Analog RGB 0.7 Vp-p/75 Ohms
Digital TMDS / DisplayPort, Separate sync: TTL Level (Positive/Negative) Composite sync: TTL Level (Positive/Negative) Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive
PC Signal Compatibility
Yes
Macintosh Signal Compatibility
Yes
Video/Sync
Analog RGB 0.7 Vp-p/75 Ohms
Digital TMDS / DisplayPort, Separate sync: TTL Level (Positive/Negative) Composite sync: TTL Level (Positive/Negative) Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive
Input Terminals/Output Terminals
Digital: DisplayPort, HDMI (2), DVI, Audio: Audio Mini-Jack x 2, External Control: Ethernet (RJ45), RS-232C, Audio: Audio Mini-Jack, External Speaker Jack (2)
On
150W
ECO Mode Standby
<2.5W
Bezel Width (Left/Right, Top/Bottom)/Dimensions (WxHxD)
0.9/0.9, 0.9/0.9 in. / 23.0/23.0, 23.0/23.0 mm, With stand: 62.5 x 37.7 x 23.9 in. / 1587.0 x 956.8 x 606 mm, Without stand: 62.5 x 36.2 x 3.4 in. / 1587 x 919.6 x 86.9 mm, Shipping: 68.4 x 45.4 x 12.5 in. / 1738 x 1153 x 318 mm
Weight/VESA Hole Configuration
Net Weight (with stand): 113.5lbs / 51.6 kg, Net Weight (without stand): 103.4 lbs. / 47 kg., Shipping: 134.2lbs / 61 kg, 400 x 400mm
Operating Temperature
32-104°F / 0-40°C
Operating Humidity
20-80%
Operating Altitude
9843 ft. / 3000m
Storage Temperature
-4-140°F / -20-60°C
Storage Humidity
10-90%
Storage Altitude
40,000 ft. / 12,192m
Warranty
3 years
