Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Groundbreaking 0.44mm Even Bezel
Power Redundancy Support
Clear View with Non-glare Panel
Uniform Color Expression
Higher Viewing Angle
Image Gap Reduction
Intuitive Menu Structure
Dedicated GUI For Portrait Orientation
Real-Time Care Service
Daisy Chain Capability
Technical Specifications
Detailed technical information for this product.
Screen Size
55"
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1,920 x 1,080 (FHD)
Brightness(Typ.,cd/m²)
700
Contrast Ratio
1,100:1
Viewing Angle (H x V)
178 x 178
Response Time
8 ms (G to G)
Surface Treatment
Haze 28%
Life Time (Typ.)
60,000 Hrs
Operation Hours
24 Hrs
Orientation
Landscape & Portrait
Input
HDMI (2), DP, DVI-D, Audio, USB, Power In, Power Loop In
Output
DP, Audio, Power Loop Out
External Control
RS232C In/Out, RJ45 (LAN) In/Out, IR In
Bezel Color
Black
Bezel Width
0.44 mm (Even)
Monitor Dimension (W × H × D)
1,210.51 x 681.22 x 86.5mm
Weight (Head)
16.8 kg
Carton Dimensions (W × H × D)
1,353 x 855 x 263 mm
Packed Weight
23.6 kg
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Type
External Power Box (An external power box (LPLG001-FV) needs to be purchased separately.)
Typ.
188W
Max.
240W
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
OPS type compatible
Yes (Piggyback)
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/ Control+
Basic
Remote Controller, RS232C Cable, Lan Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual, Power loop cable
Optional
Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), External Power Box (LPLG001-FV3)), Power cable (6m, ACC-LAPPC06), Power cable (60m, ACC-LAPPC60), OPS Kit (KT-OPSF)
