Technical Specifications
Detailed technical information for this product.
Panel Technology
S-IPS
Viewable Image Size
55"
Native Resolution
1920 x 1080
Pixel Pitch
0.63mm
Backlight Type
LED Direct-lit
Brightness (typical)
350cd/m2
Contrast Ratio (typical)
1200:1
Response Time(Gray to Gray)
9ms
Refresh Rate
60Hz
Aspect Ratio
16:9
Active Screen Area
47.6 x 26.8 in. / 1209.6 x 680.4 mm
Orientation
Landscape
Displayable Colors
More than 16.7 million
Horizontal (Analog/Digital)
31-83 kHz
Vertical
56-75 Hz
Video
Analog RGB 0.7 Vp-p/75 Ohms
Sync
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)
PC Signal Compatibility
Yes
Macintosh Compatibility
Yes
Digital
HDMI (3)
Analog
VGA 15-pin D-sub, Component, Composite (shared with Component)
Audio
HDMI Audio, Stereo Mini-Jack
External Control
RS-232C
Audio
SPDIF
On
111W
ECO Mode Standby
<0.5W
Bezel Width (Left/Right, Top/Bottom)
0.51 in./0.51 in., 0.51 in./0.58 in. ; 12.9mm/12.9mm, 12.9mm/14.7mm
Net (without stand)
48.8 x 28.0 x 3.1 in. / 1239.2 x 711.6 x 79.2mm
Shipping
54.1 x 33.9 x 7.1 in. / 1375.0 x 860.0 x 179.0 mm
Net (without stand)
34.4 lbs. / 15.6kg
Shipping
48.1 lbs. / 21.8kg
Operating Humidity
10-80%
Operating Altitude
6563 ft. / 2000m
Storage Humidity
5-85%
Storage Altitude
40,000 ft. / 12,192m
NEC
>
Optional table top stand accessory (ST-50E)
Wall Mount Kit (WMK-3257)
External OPS-DOCK
