Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
High Brightness
Visible with Polarized Sunglasses
Fan-less Design
Slim Design
High-Performance with webOS
Smart Brightness Control
Technical Specifications
Detailed technical information for this product.
Screen Size
55" class (54.64" diagonal)
Panel Technology
IPS, M+ (WRGB)
Aspect Ratio
16:9
Native Resolution
1,920 x 1,080 (FHD)
Brightness
2,500cd/m2 (Typ.), 2,250cd/m2 (Min.)
Viewing Angle (H x V)
178 x 178
Contrast Ratio
1,000:1
Lifetime
50,000 Hrs
Operation Hours
24 hrs
Orientation
Landscape & Portrait
Surface Treatment
AGLR (Haze 3%), QWP
External Control
RS232C In/Out, RJ45 In, IR Receiver In, Pixel Sensor In
Input
HDMI(2), DP, DVI-D, Audio, USB
Output
DP, Externel Speaker (L/R)
Bezel Color
Black
Bezel Width
12.0 mm (T/B), 9.9 mm (L/R)
Dimensions (w/o Stand)(W x H x D)
1,235.5 x 709.4 x 85.4 mm
Weight (Head)
26.7 kg (TBD)
Dimensions (Carton) (W x H x D)
1,360 x 231 x 844 mm
Weight (Packed)
31.9 kg (TBD)
VESA™ Standard Mount Interface
600 x 400mm
Yes
Temperature Sensor, Auto Brightness Sensor, Energy Saving, Smart Energy Saving, Tile Mode (Up to 15x15), Natural Mode@Tile Mode, Source Selection, Brightness/Contrast/Backlight, DPM Select, File Play with USB, Internal Memory, Wi-Fi Dongle Ready
Operation Humidity
10% to 80%
Operation Temperature
0°C to 45°C
Power Consumption (Smart Energy Saving)
140 W (TBD)
Power Consumption (Typ./Max)
240 W / 250 W (TBD)
Power Supply
100-240V~, 50/60Hz
Power Type
Built-in Power
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
No / No
Safety
CB / NRTL
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Link
Basic
Remote Controller(2 Batteries Included), Power Cord, HDMI Cable, Manual (ESG/EIG), IR Receiver (w/ Ambient Light Sensor)
Optional
Landscape Wall Mount (WM-L640V), Portrait Wall Mount (WM-P640V), Pixel Sensor (KT-SP0), Wi-Fi Dongle (AN-WF500)
Basic
3 Year Parts & Labor
