Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
A New Level of See-through View
High Transparency
Accurate and Vivid Colors
Intuitive PCAP Touch Screen
Protective Tempered Glass
Expandable Design
Technical Specifications
Detailed technical information for this product.
Screen Size
55"
Panel Technology
Transparent OLED Touchscreen
Aspect Ratio
16:9
Native Resolution
1,920 x 1,080 (FHD)
Refresh Rate
120Hz
Brightness (Typ.)
400/150 nits (APL 25%/100%, Without Glass)
Contrast Ratio
150,000 : 1
Color Gamut
120% BT709
Viewing Angle (H x V)
178 x 178
Color Depth
10 bit (R), 1.07 Billion Colors
Response Time
1ms (G to G)
Lifetime (Typ.)
30,000 Hrs
Operation Hours (Hours / Day)
18/7 (Moving Content Only)
Portrait / Landscape
Yes/Yes
Transparency (Typ.)
33% (Set)
Input
HDMI, DP, USB 2.0 Type A, USB 2.0 Type A (Touch Control Board only)
Output
DP, Audio, USB 2.0 Type B (Touch USB)
External Control
RS232C In/Out, RJ45 (LAN) In/Out, IR In (External IR Receiver)
Bezel Color
Matt Silver
Bezel Width
7.9/7.9/7.9/144.5 mm (T/R/L/B)
Weight (Head)
32.2 lbs/14.6kg (Head), 7.5 lbs/3.4kg (Signage Box)
Packed Weight
50.9 lbs/23.1kg
Monitor Dimensions (W x H x D)
48.2" x 32.8" x 0.3"/1,225.5 x 832.9 x 7.0 mm (Head), 30.8" x 9.4" x 1.4"/782.8 x 238.4 x 34.7 mm (Signage Box)
Carton Dimensions (W x H x D)
53" x 32.7" x 8.4"/1,345 x 945 x 207 mm
Protection Glass
Depth 3.0 mm , Tempered/Chemical Strengthening, Anti-Reflective, Shatter-Proof
Key Features
Internal Memory (16GB), Temperature Sensor, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Screen Rotation, Setting Data Cloning, SNMP, ISM Method (Image Sticking Minimization), Auto Set ID, Status Mailing, Control Manager, Crestron Connected®*, DPM, PM Mode, Wake on LAN, HDMI-CEC**, SI Server Setting
*
Network based control.
**
Compatibility may differ by equipment.
Operation Temperature Range
32° F to 104° F/0° C to 40° C
Operation Humidity Range
10% to 80%
Power Supply
100-240 Vac, 50/60 Hz
Power Type
Built-In Power
Power Consumption (Typ. / Max.)
250W/280W
Safety
CB, NRTL
EMC
FCC Class "A"/CE/KC
ErP/Energy Star
Yes (EU Only)/No
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Signage365Care
Yes
***
SuperSign CMS, Control+ and Signage365Care are optional paid software and services. Signage365Care implementation may very by region.
Basic
Remote Controller, Power Cord, IR Receiver, Phone to RS232C Gender, FFC Cables (1,600mm x 4ea), HDMI Cable (3m), Micro to A Type USB Cable (1.8m), A to B Type USB Cable, Tapes, Screws, Shield Cover Assy', Rubber Dampers, Touch Cable Holders, QSG, Regulation Book
Touch Type
P-Cap
Operating System Support
Windows
Multi touch point
Max 10 Points
