Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Built-in Interactive Touch
Embedded Writing Solution
User-friendly Smart Platform
Compatibility with AV Control System
Beacon Supported
Easy Touch Navigator on Display
Auto Signal Switching
Multi Screen with PBP/PIP
High Reliability
Technical Specifications
Detailed technical information for this product.
Screen Size
55"
Panel Technology
IPS
Native Resolution
1,920 x 1,080 (FHD)
Brightness
450 cd/m2
Viewing Angle (H x V)
178°/178°
Response Time
12 ms (G to G BW), 9.0 ms (WOT)
Surface Treatment
Hard coating (3H), Anti-glare treatment of the front polarizer (Haze 1% (Typ.)
Lifetime (Typ.)
50,000 Hrs
Operation Hours
24 Hrs
Orientation
Landscape & Portrait
Input
HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0
Output
DP, Audio Out
External Control
RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
Bezel Width (Flat Bezel)
Black
Bezel Width
32.7 mm (Even)
Monitor Dimension (W x H x D)
1,278 x 748.8 x 71.4 mm / 50.3" x 29.8" x 2.8"
Weight (Head)
28.0 kg / 61.7 lbs
Carton Dimensions (W x H x D)
1,410 x 880 x 207 mm / 55.5" x 34.6" x 8.1"
Packed Weight
33 kg / 72.8 lbs
VESA TM Standard Mount Interface
300 x 300 mm
Yes
Yes
Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning, Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
Operating Temperature Range
0°C to 40°C / 32°F to 104°F
Operating Humidity Range
10 % to 80 %
Power Supply
100 -240V~, 50/60Hz
Power Type
Built-in Power
Power Consumption (Smart Energy Saving)
70 W
Power Consumption (Typ./Max)
100 W / 115 W
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
ErP/Energy Star
NA / Yes (Energy Star 7.0)
External Media Player Attatchable
Yes (MP500/MP700)
OPS Type Compatible
Yes
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Link
Multi touch point
Max 10 Points
Protection Glass Thickness
2.8T (Anti-glare)
Interface
USB 2.0
Operating System Support
Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later)
Touch Type
IR (Scattering)
Scan Time
10 ms ↓
Basic
Remote Controller (2ea Batteries Included), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory Cover
Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT- OPSA), HDBaseT (EB-B100)
