Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
WI-FI SUPPORT
SL5B Series support Wi-Fi USB dongle connection for convenient content distribution.
SIMPLE NETWORK MANAGEMENT PROTOCOL
SNMP support ensures convenient network management.
USB CONTENT SCHEDULING
Play and schedule contents with a USB connection-no server connection required.
LG SUPERSIGN
Run messages on up to 50 display screens in the form of a billboard without any additional hardware. Advertisements, ...
Read More
CONFORMAL COATING
EXTENDED CARE
Technical Specifications
Detailed technical information for this product.
Screen Size
55" class (54.64" measured diagonally)
Panel Technology
IPS
Contrast Ratio
1,100:1
Response Time
12ms(G to G BW)
Dynamic Contrast Ratio
500,000:1
Brightness
450cd/m2
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Viewing Angle (H x V)
178°/178°
Pixels (H x V x 3)
6220800
Surface Treatment
Hard Coating (3H), Anti-glare treatment of the front polarizer (Haze 1% (Typ.))
Orientation
Portrait & Landscape
Color Depth
16.7 Million
Lifetime (Typ.)
50,000 Hrs
Color Gamut
68%
Operation Hours
18 Hr
RS232C
Yes (1)
RJ35
Yes (1)
Audio In
Yes (1)
HDTV Formats
HDMI : 720p, 1080i, 1080p
USB
Yes (2)
Digital DVI
Yes (1)
Analog RGB
Yes (1)
IR receiver
Yes (1)
HDMI
Yes (1)
DP
No
Pixel Sensor
No
USB Cloning
Logo image download, EzDownload, Sent to USB, Receive from USB
Key Operation
IR operation, Local key operation
HDMI-CEC
Yes
ISM Method
Normal, White Wash, Color Wash, Orbiter, inversion, Washing Bar, User image
DPM Select
Yes
Energy Saving
Yes(Minimum, Medium, Maxium, Screen off)
Source Selection
RGB, HDMI, DVI, USB1, USB2
Time
Clock, On/Off Time, Auto Off, Automatic Standby
Input Label
Yes (PC / DTV)
File Play with USB
Yes
Power Indicator On/Off
No
Brightness / Contrast / Backlight
Yes
Position / Size
Yes
Auto Config / Phase
Yes
Advanced
Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma
Language
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek
Natural Mode @ Tile Mode
Yes
Temp Sensor
Yes
Screen Off Schedule
Yes
Time Sync Clock
Yes
PM mode
Yes
Holiday Schedule
Yes
Firmware Update (LAN)
Yes
Local Auto Time
Yes
Overlay touch
Yes
Still Image Diagnosis
Yes
Limited Mode
Input source change, Menu Display, OSD Display
Power On Default
Input source, A/V Setting, Aspect Ratio
Power On Status
Standard, PWR, LST
Wake on LAN
Yes
Digital Audio Input
Yes
Power On Delay
0~255
Fail Over
USB, RGB, DVI, HDMI
SuperSign Server Setup
Player name, Server IP setting, Server IP Status
No Signal image (Up to 5MB)
Yes
Calibration mode
Yes
Easy Brightness Control
Yes
Content scheduling
USB
Wi-Fi
Dongle Ready
Sound Mode
Standard, News, Music, Cinema, Sport, Game
Audio Power
20W (10W x 2) for External Speaker
Clear Voice II
Yes
Balance
Yes
Virtual Surround
Yes
Equalizer
Yes
Operating Temperature Range
0°C to 40°C / 32°F to 104°F
Operating Humidity Range
10 % to 80 %
Tile Mode
Yes (Up to 15x15)
Bezel Color
Black
Bezel Width
11.9mm (T/R/L), 18mm (B)
Monitor Dimension (W x H x D)
48.7”x28.2 x1.5”
Monitor Weight
38.1lbs
Monitor w/opt. Stand Dimensions (W x H x D)
48.7” x 30.4” x 8.6”
Monitor w/opt. Stand + Speaker Dimensions (W x H x D)
48.7” x 30.4” x 8.6”
Monitor Weight w/opt Stand + Speaker
46.52lb
Carton Dimensions (W x H x D)
52.4”x31.8”x6.7”
Packed Weight
47.4lbs
VESA TM Standard Mount Interface
300 mm x 300 mm
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption-DPM
0.7W
Power Consumption-Power Off
0.5 W
Power Consumption-Typ
85 W
External Speaker Out
YES (L/R)
Audio Out
Yes
DVI
No
RS232C OUT
Yes (1)
Basic
Remote Controller (includes 2 batteries), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
SuperSign W-Lite
Yes
SuperSign Elite-c
Yes
External Media Player Attatchable
Yes (MP500/MP700)
OPS Type Compatible
No
Safety
UL / cUL / CB / TUV / KC /
EMC
FCC Class "A" / CE / KCC
ErP
YES
EPEAT Gold
Yes
