Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
SIMPLE NETWORK MANAGEMENT PROTOCOL
SNMP support ensures convenient network management.
WI-FI SUPPORT
SH7DB Series support Wi-Fi USB dongle connection for convenient content distribution.
SLIM DESIGN | NARROW BEZEL
LG’s monitors featuring a Direct-LED Backlight, have a stylishly slim design that fit perfectly into narrow spaces wh...
Read More
CONFORMAL COATING
Technical Specifications
Detailed technical information for this product.
Contrast Ratio
1,300:1
Response Time
8ms (G to G BW) Typical
Dynamic Contrast Ratio
500,000:1
Brightness
700cd/m2
Screen Size
55" class (54.6” diagonal)
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Viewing Angle (H x V)
178°/178°
Pixels (H x V x 3)
6220800
Surface Treatment
Hard Coating (3H), Anti-Glare Treatment of the Front Polarizer (Haze 10%)
Orientation
Portrait & Landscape
Color Depth
1.07 Billion
Lifetime (Typ.)
50,000 Hrs
Color Gamut
72%
Operation Hours
24 Hr
Sound Mode
Standard, News, Music, Cinema, Sport, Game
Audio Power
20W (10W x 2) for External Speaker
Clear Voice II
Yes
Balance
Yes
Virtual Surround
Yes
Equalizer
Yes
UPC
719192197480
Warranty
3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available
Limited Warranty
3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available
Audio In
Yes
HDTV Formats
HDMI : 720p, 1080i, 1080p
Digital DVI
Yes
HDMI
Yes
DP
Yes
Digital
Yes
Audio Out
Yes
RS232C OUT
Yes
DP Out
Yes
USB Cloning
Logo image download, EzDownload, Sent to USB, Receive from USB
Key Operation
IR operation, Local key operation
Lock Mode
USB
HDMI-CEC
Yes
ISM Method
Normal, White Wash, Color Wash, Orbiter, inversion, Washing Bar, User image
DPM Select
Yes
Source Selection
DVI-D, HDMI, Display Port, USB, OPS,RGB
Time
Clock, On/Off Time, Auto Off, Automatic Standby
File Play with USB
Yes
Language (OSD/ USB Playback)
English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Portuguese (Europe), Dutch, Czech, Greek
Brightness / Contrast / Backlight
Yes
Position / Size
Yes
Auto Config / Phase
Yes
Advanced
Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma
Natural Mode @ Tile Mode
Yes
Time Sync Clock
Yes
Holiday Schedule
Yes
Local Auto Time
Yes
Still Image
Yes
Limited Mode
Input source change, Menu Display, OSD Display
Power On Default
Input source, A/V Setting, Aspect Ratio
Wake on LAN
Yes
Fail Over
USB, RGB, DVI, HDMI
SuperSign Server Setup
Player name, Server IP setting, Server IP Status
Calibration mode
Yes
Easy Brightness Control
Yes
Content scheduling
USB
Wi-Fi
Dongle Ready
Local Time Auto Setting
Yes
OPS PC Power Control
Sync On, Sync On/Off, Disable
Frameware Update (LAN)
Yes
Operating Temperature Range
0°C to 40°C / 32°F to 104°F
Operating Humidity Range
10 % to 80 %
Tile Mode
Yes (Up to 15x15)
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption-DPM
0.7 W (DP)
Power Consumption-Power Off
0.5 W
Power Consumption-Typ
140 W
DPM
0.7 W (DP)
Basic
Remote Controller (include battery 2 each), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
Optional
SP-2100 (External Speaker), ST-200T, LSW440S, AN-WF500 (WiFi USB Dongle), KTOPSA (OPS Kits), KT-SP0 (Pixel Sensor)
Bezel Color
Black
Bezel Width
7.4mm (T/L/R/U even)
Packed Weight
55.6lbs
Monitor Dimension (W x H x D)
48.4” x 28.1” x 1.3”
VESA TM Standard Mount Interface
400mm x 400mm
Carton Dimensions (W x H x D)
52.4” x 32.1” x 6.9”
Monitor w/opt. Stand Dimensions (W x H x D)
48.4” x 30.6” x 11.7”
Monitor w/opt. Stand + Speaker Dimensions (W x H x D)
48.4” x 30.6” x 11.7”
Monitor Weight w/opt. Stand
48.7lbs
Monitor Weight w/opt Stand + Speaker
50.5lbs
Monitor Weight
45.6lbs
Safety
UL / cUL / CB / TUV / KC /
EMC
FCC Class "A" / CE / KCC
ErP
YES
SuperSign W-Lite
Yes
SuperSign Elite-c
Yes
External Media Player Attatchable
Yes (MP500/MP700)
OPS Type Compatible
Yes
