Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
Essential Commercial TV with Multiple Use
EASIER MAINTENANCE
Compatibility with AV Control Systems
DPM (Display Power Management)
USB Data Cloning
Time Scheduler
External Speaker Out
Technical Specifications
Detailed technical information for this product.
Speaker System
2.0 ch
Speakers
10W + 10W
EMC
FCC
Safety
UL
Backlight Unit Type
Direct BLU
Brightness
400 nits
HDR_HLG
Yes
Inch
49"
Life Span
30,000 hrs
Resolution
1,920 x 1,080 (FHD)
TruMotion / Refresh Rate
60 Hz
Broadcasting System - Digital TV Reception (Terrestrial, Cable, Satellite)
ATSC (QAM / VSB), Analog NTSC
Ease of Installation - EzManager (Simplicity)
Yes
Ease of Installation - USB Cloning
Yes
Hospitality - External Speaker Out
Yes (Int / Fixed, 3.5 mm, Stereo, Single-Ended Type (GND, L+, R+), 1W with 8Ω)
Hospitality - Hotel Mode / PDM / Installer Menu
Yes (PDM)
Hospitality - Insert Image
Yes
Hospitality - Lock Mode
Yes
Hospitality - RJP (Remote Jack Pack) Compatibility
Yes LG / Teleadapt (RS232C), Teleadapt / Guestlink (HDMI CEC)
Hospitality - Welcome Screen (Splash Image)
Yes
Hospitality - Welcome Video
Yes
Management - Diagnostics
Yes (USB)
Management - HTNG-CEC
Yes (1.4)
Management - Multi-IR Code
Yes
Management - SI Compatible (TVLink Interactive)
Yes (RS232C, HDMI)
Management - Simplink (HDMI-CEC)
Yes (1.4)
Management - SNMP
Yes
Management - Wake on LAN
Yes
Setting Option - Auto Off / Sleep Timer
Yes / Yes
Setting Option - Motion Eye Care
Yes
Setting Option - Smart Energy Saving
Yes
Signage (Corporate / Retail) - Crestron Compatibility
Yes
Signage (Corporate / Retail) - DPM (Digital Power Management)
Yes
Signage (Corporate / Retail) - NTP Sync Timer
Yes
Signage (Corporate / Retail) - Time Scheduler
Yes
SuperSign SW Compatibility - Control / Control Plus
Yes (Control)
USB - USB Auto Playback / USB Auto Playback + Playlist
Yes / Yes
AV In
1 (Share with Component)
Component In (Y, Pb, Pr-Video)
1 (RCA5 Type)
Digital Audio Out (Coaxial / Optical)
1 (Optical)
External Speaker Out (3.5 mm Phone Jack)
1 (Spk-Out Fixed 0.01 W~1.0 W)
HDMI In
2 (1.4)
PC Audio Input
1 (Share with Component Audio)
RF In
1 (Tuner)
RGB In (D-Sub 15 pin) - PC
1
RJ45 (Usage Purpose)
1
RS-232C (D-Sub 9 pin)
1
USB
1 (2.0)
Front Color
Ceramic Black
Size in Shipping
47.0" x 30.3" x 6.2" / 1,193 x 770 x 158 mm
Size with Stand
43.7" x 27.8" x 9.3" / 1,110 x 705 x 235 mm
Size without Stand (depth to back side VESA mount)
43.7" x 25.6" x 2.8" 1,110 x 650 x 72 mm
Size without Stand (depth to lower back side speaker)
43.7" x 25.6" x 3.2" 1,110 x 650 x 81 mm
Stand Type
2 Pole
VESA Compatible
300 x 300
Weight in Shipping
29.5 lbs / 13.4 kg
Weight with Stand
25.1 lbs / 11.4 kg
Weight without Stand
24.9 lbs / 11.3 kg
UPC
7 19192 63064 2
Warranty
Two-Year Limited Warranty
Power Consumption Max.
100 W
Power Supply (Voltage, Hz)
120 V / 50-60 Hz
Standby Power Consumption
Under 0.3 W
