Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
UltraWide Quad HD on IPS Display
Thunderbolt™ 2.0 (x2)
sRGB over 99％
USB 3.0 Quick Charge
On-Screen Control
Screen Split 2.0
Easy Setup
Technical Specifications
Detailed technical information for this product.
Panel Size
34" class (34" measured diagonally)
Panel Type
IPS
Color Gamut (CIE 1931)
sRGB 99%
Color Depth (Number of Colors)
10bits (8bit+FRC), 1.07B
Resolution
3440 x 1440
Viewing Angle (CR≥10)
178/178
Pixel Pitch (mm)
0.2325 x 0.2325 mm
Contrast Ratio (Original)
1000:1
Brightness
300 cd/m² (Typ.)
DFC
Mega
Response Time (on/off)
14ms (Typ)
Response Time
5ms
HDMI
Yes (ver2.0, 2ea)
DisplayPort
Yes (ver1.2)
Headphone Out
Yes
USB Upstream Port
Yes (USB3.0 1ea)
USB Downstream Port
Yes (USB3.0 2ea) * included Quick Charge for port 1
Thunderbolt
Yes (2ea)
Audio Tuning
MaxxAudio
Type
Adapter
Input
100 ~ 240V
Power Save/Sleep Mode (Max)
1.2W
Normal On (Typ)
70W
Normal On
56.73W
DC Off(Max)
0.3W
DisplayPort (H-Frequency)
30~90Hz
DisplayPort (V-Frequency)
56 ~ 61Hz
HDMI (H-Frequency)
30~90kHz
HDMI (V-Frequency)
56~61Hz
Thunderbolt (V-Frequency)
56~61Hz
Thunderbolt (H-Frequency)
30~90Hz
Black Stabilizer
Yes
DAS Mode
Yes
FreeSync
Yes (DP 40~ 60 Hz)
Quick Charge
Yes
Six Axis Control
Yes
PBP
Yes
PIP
PIP mode in Screen Split
Key Lock
Yes
Picture Mode
Custom, Reader, Photo, Cinema, Dark Room 1, Dark Room 2, Color Weakness, FPS Game 1, FPS Game 2, RTS Game, Custom (Game)
Game Mode
Yes
Color Calibrated
Yes
Flicker Safe
Yes
Reader Mode
Yes
Dual Controller
Yes
Ratio
Wide, Original, Cinema 1, Cinema 2, 1 : 1
Smart Energy Saving
Yes
HDCP
Yes
DDC/CI
Yes
Automatic Standby
Yes
Dual EDID (H/W)
Yes
Screen split2.0 (in OSC)
Yes
On-Screen Control (OSC)
Yes
My Display Preset (in OSC)
Yes
Tilt (Angle)
-5~20 Degree
Height (Range)
120mm
Monitor (with Stand)
32.7” x 9.9” x 16.9” (Down) 32.7” x 9.9” x 21.6” (Up)
Weight (with Stand)
18.5 lbs
Monitor (without Stand)
32.7” x 1.9” x 15”
Weight (Without Stand)
13.9 lbs
Dimensions (Box) (W x H x D)
38.5” x 8.1” x 20.6”
Weight (Box)
24.9 lbs
VESA Standard Mount Interface
100mm x 100mm
Packing Material
EPS
Stand Packing Type
Base Detach
Stacking Type
Vertical
Box Printing Type
Offset
Handle
Hand Hole
UL(cUL)
Yes
TUV-Type
Yes
FCC-B, CE
Yes
ErP
Yes
CCC (for China)
Yes
BSMI (for Taiwan)
Yes
Power Cord
Yes
HDMI
Yes
Display Port
Yes
Cable Holder
Yes
Limited Warranty
3-Year Limited Warranty (Parts/Labor/Backlight)
UPC
7 19192 60727 9
