NEC 49" 4K UHD Display with Integrated ATSC/NTSC Tuner
NEC 49" 4K UHD Display with Integrated ATSC/NTSC Tuner
NEC 49" 4K UHD Display with Integrated ATSC/NTSC Tuner
NEC

NEC 49" 4K UHD Display with Integrated ATSC/NTSC Tuner

Call for price
The NEC direct view indoor LED FE Series provides vibrant LED imaging in a cost effective package and are the ideal solutions for today's demanding applications. This 220" UHD kit is built with NEC's 2.53mm LED-FE025i2 module designed to deliver...
Request a Quote
100% Satisfaction
Guaranteed
Quick & Easy
Returns Policy
Always Get
Our Best Price

SKU: LED-FE025I2-220IN

UPC: 805736071986

MFG Part: LED-FE025I2-220IN

Technical Specifications

Free shipping on orders over $500.

30-day return policy for unopened items.

Contact us for warranty claims and support.

Proudly partnered with:

Built for Commercial Excellence

Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.

220” diagonal screen size

FHD (1920x1080) resolution with a refresh rate of up to 3840 Hz

Kit includes everything needed for an LED installation including the LED modules, power bar, LED controller, mounting...

Read More

Front serviceable modules allowing for installation in difficult to access areas

Pixel cards are hot-swappable and can be replaced without turning the display off

Shallow depth (3.2” installed) and reduced weight allow for greater installation flexibility and also meet ADA requir...

Read More

Improved LED performance with better contrast, viewing angles, brightness uniformity and color uniformity

Standard installation included.

CCC

CE

ETL

FCC Class A

RoHS

Technical Specifications

Detailed technical information for this product.

Panel Technology Direct View LED
Viewable Image Size 220 in.
Aspect Ratio 16:9
Native Resolution 1920x1080
Module Resolution 240 x 135
Pixel Configuration 3-1 SMD (Black)
Pixel Pitch 2.53 mm
Brightness (maximum) 1000 cd/m2
Contrast Ratio (typical) 5000:1
Viewing Angle (typical) 80/80 horizontal / 70/70 vertical
Refresh Rate 2880 Hz
Active Screen Area 191.2 x 108 in. / 4864 x 2736 mm
Orientation Landscape
Dimming Capability 256 levels
Color Processing Up to 16 bit
Displayable Colors 281 Trillion
Color Temperature (Max) (°K) 9500
Color Temperature (Typical) (°K) 6500
Color Temperature (Min) (°K) 3000
Gamma (Max) 4.0
Gamma (Typical) 2.8
Gamma (Min) 1.0
Lifetime 100,000 hours
External Control/Input Terminals 1 x GenLock; 1 x LAN, Digital: 1 x 3G SDI; 1 x DVI-D; 1 x HDMI, External Control: RS232 / USB
On 3008Watts
Power Consumption (max) 7680 Watts
Dimensions (WxHxD) Without stand: 193.1 x 112.4 x 3.2 in. / 4907 x 2856 x 81 mm
Weight Net Weight (without stand): 1053.8 lbs. / 478 kg. Shipping: 1453.3 lbs / 659.2 kg Servicability: Front Service IP Level: IP20 Certifications: CCC CE ETL FCC Class A RoHS
Operating Temperature -4° to 104°F / -20° to 40°C
Operating Humidity 10% to 80%
Storage Temperature -4° to 113°f / -20° to 45°c
Storage Humidity 10% to 85%
Environment Indoor
Warranty 2 years
