Built for Commercial Excellence
Not just a monitor; a dedicated commercial video wall component engineered for flawless, long-term performance.
LG LAPE Premium Fine-pitch DVLED Signage
The Power to Choose
Create True Curved Screens
REALISM THROUGH LIFELIKE COLORS
Color Depth with 16-bit Color Processing
SMOOTH PLAYBACK IN DYNAMIC MOTION
POWER/SIGNAL REDUNDANCY SUPPORT
PRECISE FHD/UHD SCEEN CONFIGURATION
SMART HIGH PERFORMANCE SYSTEM CONTROLLER
INTUITIVE MANAGEMENT SOFTWARE
REAL-TIME 365 CARE SERVICE
EASY TO HANDLE & INSTALL
Easy Module Alignment
FRONT INSTALLATION & SERVICE
Technical Specifications
Detailed technical information for this product.
Pitch Name
P2.5
Pixel Configuration
3 in 1 SMD
Pixel Pitch(mm)
2.50
Module Resolutions (W x H)
96 x 72
Module Dimensions(W x H, mm)
240 x 180
Weight per Module (kg)
0.36
No. of Modules per Unit Case (W x H)
2 x 3
Unit Case Resolution (W x H)
192 x 216
Unit Case Dimensions (W x H x D, mm)
480 x 540 x 105
Unit Case Surface Area (m²)
0.259
Weight per Unit Case (kg/unit)
10.1
Weight perSquare Meter (kg/m²)
37.4
Physical Pixel Density (pixels/m²)
160,000
Flatness of Unit Case (mm)
+0.2
Unit Case Material
Die Casting Aluminum
Service Access
Front and Rear
Min. Brightness (After Calibration)
700 cd/m²
Color Temperature
3,200 - 9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
95%
Color Uniformity
+0.0015Cx, Cy
Contrast Ratio
6,000
Processing Depth (bit)
16(HDR10)
Power Consumption (W/Unit, Avg.)
90
Power Consumption (W/Unit, Max.)
180
Power Consumption (W/m², Max.)
700
Power Supply (V)
100 to 240
Frame Rate (Hz)
50/ 60
Refresh Rate (Hz)
3,840
Lifetime (Half Brightness, hrs)
50,000 (It is subject to LED package spec)
Operating Temperature (°C)
0°C to + 40°C
Operating Humidity
10-80%RH
EMC
FCC Class "A" / CE / KC
Environment
RoHS
Controller
LCLG005
Video Inputs
HDMI In, DP In, OPS In, USB
Control
RJ45 In, RS232C In/out
Special Features
HDR10, Temperature Sensor, Power Detection
